| Description | 20’ x 8’ x 8’6’’ | 40’ x 8’ x 8’6’’ |
| Size and Type grouping code | 20PC | 40PC |
| Dimensions & type code | 22P3 | 42P3 |
| Internal dimensions Length between end headers (mm) Length between corner posts (mm) Width between corner posts (mm) Width of floor (mm) Height (mm) |
5,920 5,634 2,224 2,208 2,213 |
12,054 11,652 2,227 2,374 1,959 |
| Maximum gross weight (kg) | 34,000 | 45,000/50,000 |
| Average tare (kg) | 2,750 | 4,900/5,100 |
| Maximum payload (kg) | 31,250 | 40,100/44,900 |
| Securing rings Number per side |
12 |
32 |
