Description | 20’ x 8’ x 8’6’’ | 40’ x 8’ x 8’6’’ | 40’ x 8’ x 9’6’’ | 45’ x 8’x 9’6’’ |
Size and Type grouping code | 20GP | 40GP | 40HC | 45HC |
Dimensions & type code | 22G1 | 42G1 | 45G1 | L5G1 |
Internal dimensions Length (mm) Width (mm) Height (mm) |
5,900 2,352 2,393 |
12,034 2,352 2,395 |
12,034 2,352 2,700 |
13,556 2,352 2,700 |
Door opening Width (mm) Height (mm) |
2,340 2,280 |
2,340 2,280 |
2,340 2,585 |
2,340 2,585 |
Nominal capacity (cu.m.) | 33.2 | 67.8 | 76.4 | 86.0 |
Maximum gross weight (kg) | 30,480 | 30,480/32,500 | 30,480/32,500 | 30,480 |
Average tare (kg) | 2,230 | 3,720 | 3,900 | 4,700 |
Maximum payload (kg) | 28,250 | 26,760/28,780 | 26,580/28,600 | 25,780 |
Securing rings Quantity Resistance (kg/each) |
20 1,500 |
32 1,500 |
32 1,500 |
40 1,500 |
