Pallet Capacity
Description | 40’ HC | 40’ HC PW | 45’ HC | 45’ HC PW |
1 m x 1.2 m pallets | 21 | 24 | 24 | 26 |
1.2 m x 0.8 m Europallets | 25 | 30 | 27 | 34 |
Technical Data
Description | 40’ x 2462 mm x 9’6’’ | 40’ x 2462 mm x 9’6’’ |
Size and Type grouping code | 40 HW | 45HW |
Dimensions & type code | 4EG0 | LEG0 |
Internal dimensions Length (mm) Width (mm) Height (mm) |
12,095 2,444 2,692 |
13,624 2,420 2,687 |
Door opening Width (mm) Height (mm) |
2,400 2,584 |
2,360 2,580 |
Cubic capacity (cu.m.) | 79.60 | 85.25 |
Maximum gross weight (kg) | 34,000 | 34,000 |
Tare weight (kg) | 4,260 | 4,980 |
Maximum payload (kg) | 29,740 | 29,020 |
